Chronic Total Occlusions Balloon Catheter
“Lowest Profiles with Improved pushability for even the most challenging cases”
Designed to achieve greater crossability even in the most complex chronic occlusions.
The combination of the low crossing profile, tapered tip technology and extra support shaft can traverse even the most difficult occlusions with the least resistance.
- The 3-in-1 balloon: CTO (1.00mm), high-pressure (18 bar RBP) & OTW (used instead of a microcatheter)
- Improved 2-pleats folding process
- Ultra-low 0.016’’ soft, yet durable tip, which is designed to cross Chronic Total Occlusions
- Central Platinum-Iridium marker band for high radiopacity and lower balloon distal profiles for enhanced crossability
- Rontis’ proprietary material blend ensures ultra low profile and extremely durable balloons
- High pressure capability, providing extreme resistance to potential puncture
- Homeogeneous expansion throughout the entire balloon length
- Rontis’ proprietary hydrophilic coating HiFlow for smoother navigation through the most challenging vasculature
- Low profile shaft, ensuring more penetration power
- Fully integrated hypotube-shaft transition optimizes pushability
TECHNICAL DATA
Europa Ultra CTOTM semi-compliant coronary balloon catheter
| Mode of exchange: | Rx & OTW | |
| Balloon material/characteristic: | modified polyamide / semi – compliant | |
| Radiopaque markers: | 1 (Pt-Ir) in the middle of the balloon’s working length | |
| Guiding Catheter compatibility (min): | 5F | |
| Usable Catheter Length: | 140 cm (Rx), 150cm (OTW) | |
| Distal shaft (Rx): | 2.4F | |
| Hypotube (Rx): | 2.0F | |
| Double lumen shaft (OTW): | 2.6F | |
| Guidewire compatibility (max): | 0.014” | |
| Nomimal pressure: | 8 bar | |
| Rated Burst Pressure: | 18 bar | |
| Coating: | Hydrophilic, HiFlow | |
| Total shelf life: | 4 years | |
User trainings are performed upon request. Due to confidentiality, for further user information/videos please contact us at endovascular@rontis.com.
