Balloon Catheter – Rx – 0.018″
“The only 0.018″ solution now 4-SF for cross over”
New and versatile balloon catheter engineered to meet the challenges of renal and infra-inguinal procedures through smaller diameter introducer sheath combining reliable deliverability and trackability.
- UP Technology – Ultimate Pressure. Facilitates advancement through complex lesions taking advantage of the monorail catheter design
- New Rx design with new and reinforced PTFE coated hypotube ensuring balance of high pushability, excellent flexibility and best kink resistance
- Modified high performance balloon material ensures lower profile for improved advancement through tortuous vasculature
- Rontis’ proprietary hydrophilic coating, HiFlow
- 2 Gold marker bands for accurate positioning
TECHNICAL DATA
TritonTM Plus Peripheral Balloon Catheter – Rx – 0.018”
Mode of exchange: | Rx | |
Baloon material / characteristic: | modified polyamide / semi – compliant | |
Guidewire compatibility (max): | 0.018” | |
Sheath compatibility (min): | 4F ( Ø 3.0-4.5 mm) 5F ( Ø 5.0- 6.5 mm) 6F ( Ø 7.0- 8.0 mm) |
|
Radiopaque markers: | 2, Gold | |
Usable catheter length: | 80 cm, 135 cm | |
Distal Shaft: | 3.2 – 3.5 Fr | |
Hypotube: | 2.6 Fr | |
Nominal pressure: | 6 atm | |
Rated Burst Pressure: | 15-18 atm | |
Average Burst Pressure: | up to 26 atm | |
Coating: | Hydrophilic, HiFlow | |
Total shelf life: | 4 years |
