Balloon Catheter – Rx – 0.018″
“The only 0.018″ solution now 4-6F for cross over”
Versatile balloon catheter engineered to meet the challenges of renal and infra-inguinal procedures through smaller diameter introducer sheath combining reliable deliverability and trackability.
- Facilitates advancement through complex lesions taking advantage of the monorail catheter design
- Rx design with reinforced PTFE coated hypotube ensuring balance of high pushability, excellent flexibility and best kink resistance
- 0.018’’ guidewire compatibility provides significant support for treating challenging lesions
- Range of balloon diameters based on 0.5mm “steps” allows for a particularly accurate catheter selection.
- Modified high performance balloon material ensures lower profile for improved advancement through tortuous vasculature
- Rontis’ proprietary hydrophilic coating, HiFlow
- 2 Gold marker bands for accurate positioning
TECHNICAL DATA
Triton® Plus Peripheral Balloon Catheter – Rx – 0.018”
| Mode of exchange: | Rx | |
| Baloon material / characteristic: | modified polyamide / semi – compliant | |
| Guidewire compatibility (max): | 0.018” | |
| Sheath compatibility (min): | 4F ( Ø 3.0-4.5 mm) 5F ( Ø 5.0- 6.5 mm) 6F ( Ø 7.0- 8.0 mm) |
|
| Radiopaque markers: | 2, Gold | |
| Usable catheter length: | 80 cm, 135 cm | |
| Distal Shaft: | 3.2 – 3.5 Fr | |
| Hypotube: | 2.6 Fr | |
| Nominal pressure: | 6 bar | |
| Rated Burst Pressure: | 15-18 bar | |
| Coating: | Hydrophilic, HiFlow | |
| Total shelf life: | 4 years | |
User trainings are performed upon request. Due to confidentiality, for further user information/videos please contact us at endovascular@rontis.com.
